FC300L2 - Experiment
Self-Regulating Siphon
A clear acrylic, self-regulating siphon that demonstrates the automatic adjustment of its discharge over a wide range while maintaining a mostly constant water level upstream. The siphon passes a mixture of air and water.
For use with an FC300 Flow Channel, not included.
Description
Alternatives
Spillway
FC300E - Experiment
The spillway comes in four parts: the spillway, detachable ski jump and plain apron with removable toothed block. It is used to observe and calculate flow and energy dissipation over spillways.
The spillway can also be used with the Energy Dissipation (FC300e3) to extend the range of possible experiments.
For use with an FC300 Flow Channel, not included.
Ogee Weir with Tappings
FC300E2 - Experiment
Similar to the Spillway (FC300e) but with the addition of ten pressure tappings placed over the crest and face of the weir. The tappings are connected to a suitable Manometer (FC300w) or 32-Way Pressure Display (FCA1). It is used to study the pressure differences over the crest and face of an Ogee weir.
The spillway can also be used with Energy Dissipation (FC300e3) to extend the range of possible experiments.
For use with an FC300 Flow Channel, not included.
Siphon Spillway
FC300L - Experiment
A clear acrylic spillway that demonstrates the effect of a siphon spillway and the increased flow permitted when compared with an ordinary spillway of a similar height.
For use with an FC300 Flow Channel, not included.
