MULTI-TUBE MANOMETER

The multi-tube manometer is an ancillary to the AF10base module and its experiment modules. It fits on or near to the AF10 and connects to pressure tappings on the optional experiment modules. Some experiment modules may only have two or three pressure tappings but others use up to 12 tappings. This makes the multitube manometer essential to see all the pressures at the same time.

The manometer uses clean water as a working fluid for safety and convenience. TecQuipment supply coloured non-toxic dye to add to the water so students can see the water levels more clearly.

A small reservoir to the side of the manometer tubes holds the water. Students can adjust the reservoir height to change the datum of the water levels in the manometers.
Adjustable feet allow students to accurately level the manometer before use.

Thumbscrew fixings allow the user to incline the manometer tubes from fully vertical to 80 degrees. This changes the magnification (sensitivity) of the manometer for reading very small changes in pressure. The User Guide gives details of the magnification factors for different angles. A set of markings to the side of the manometer shows angles in 5 and 10 degrees division.
