AF1300A - Experiment

CYLINDER MODEL

A cylinder model with a single pressure tapping point for use with the AF1300 Subsonic Wind Tunnel.

PDF datasheet

OR CALL US TO DISCUSS +44 1159 722 611

Description

CYLINDER MODEL

A cylinder model that spans the full width of the working section of the Subsonic Wind Tunnel (AF1300). A holder (included with the wind tunnel) supports the model in the tunnel. Also, the optional Three-Component Balance (AF1300t, available separately) or the two-component Basic Lift and Drag Balance (AF1300z, available separately) will support the model.

The model includes a single pressure tapping so, by rotating the model, students can find the pressure distribution around the cylinder. TecQuipment offers several suitable pressure-measuring instruments (available separately).

Using a Pitot tube, students can traverse the model wake to find the downstream pressure distribution and find the drag on the model. They can compare this to direct measurements, obtained using a balance.

TecQuipment’s Smoke Generator (AFA11, not included) increases the educational value of the experiments by showing the flow of air around the model.

Read more +
Essential Base Units
SUBSONIC WIND TUNNEL 305 mm Package Af1300S 0618

SUBSONIC WIND TUNNEL 305 mm

VDAS AF1300S - Package

A starter set consisting of the Subsonic Wind Tunnel 305 mm (AF1300), Basic Lift and Drag Balance (AF1300z) and a set of Three-Dimensional Drag Models (AF1300j).

Recommended Ancillaries
Balance Angle Feedback AFA4 1204

BALANCE ANGLE FEEDBACK UNIT

AFA4 - Ancillary

Compact instrument that fixes to the Three Component Balance (AF1300T). It measures the angle positions of models mounted in the balance and feeds the information directly to the Versatile Data Acquisition System (VDAS®).

Differential pressure transducer AFA5 0804

DIFFERENTIAL PRESSURE TRANSDUCER

AFA5 - Ancillary

Digital differential pressure measurement and display unit for use with TecQuipment’s Subsonic Wind Tunnel (AF1300).

Afa7 Pitot Static Traverse

PITOT STATIC TRAVERSE (DIGITAL)

AFA7 - Ancillary

A traversing Pitot static tube with electronic position measurement for use with TecQuipment’s Subsonic Wind Tunnels (AF1300, AF1300s, AF1600s).

THREE COMPONENT BALANCE Af1300T

THREE COMPONENT BALANCE

AF1300T - Ancillary

Supports wind tunnel models in the AF1300 Subsonic Tunnel and measures their lift, drag and pitching moment.

BASIC LIFT AND DRAG BALANCE AF1300z 0619

BASIC LIFT AND DRAG BALANCE

AF1300Z - Ancillary

A two-component balance that measures lift and drag forces on models mounted in the AF1300 Subsonic Wind Tunnel.

Alternatives
Drag Force Af12 0404

DRAG FORCE

AF12 - Experiment

Allows students to investigate the direct and indirect measurement of drag on various shapes and to calculate and analyse the drag coefficient by different methods.
